Image Sensor
11.8 Progressive Scan CMOS
Max. Resolution
3200 × 1800
Min. Illumination
Color 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
Shutter Time
1 s to 1100,000 s
Day & Night
IR cut filter
Angle Adjustment
Pan 0° to 360°,tilt 0° to 90°,rotate 0° to 360°
Lens
Lens Type
Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 108.8°, vertical FOV 56.4°, diagonal FOV 134.3°
4 mm, horizontal FOV 93.3°, vertical FOV 47.2°, diagonal FOV 114.2°
Lens Mount
M16
Iris Type
Fixed
Aperture
F1.0
Depth of Field
2.8 mm 3.3 m to ∞
4 mm 3.8 m to ∞
DORI
DORI
2.8 mm D 89 m, O 35 m, R 17 m, I 8 m
4 mm D 109 m, O 43 m, R 21 m, I 10 m
Illuminator
Supplement Light Type
IR,White Light
Supplement Light Range
Up to 60 m
Smart Supplement Light
Yes
IR Wavelength
850 nm
HEOP
Open Resources
Memory 40 MB,
Smart RAM 450 MB,
eMMC 2 GB
Computing Power
1.5 TOPS
Open Capability
HEOP 2.0 OpendevSDK
Deep Learning Structure
Caffe,PyTorch,TensorFlow,PaddlePaddle,ONNX
Programming Language
C,C++
Video
Main Stream
50 Hz
25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz
30 fps (3200 × 1800，2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Fourth Stream
50 Hz 10 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz 10 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression
Main stream H.265H.264H.264+H.265+,
Sub-stream H.265H.264MJPEG,
Third stream H.265H.264,
Fourth stream H.265H.264MJPEG,
Video Bit Rate
32 Kbps to 16 Mbps
H.264 Type
Baseline Profile,Main Profile,High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR,VBR
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Region of Interest (ROI)
5 fixed regions for main stream and sub-stream
e-PTZ
Support Patrol and Auto Tracking settings
Audio
Audio Type
Mono sound
Audio Compression
G.711G.722.1G.726MP2L2PCMMP3AAC-LC
Audio Bit Rate
64 Kbps (G.711ulawG.711alaw)16 Kbps (G.722.1)16 Kbps (G.726)16 Kbps to 64 Kbps (AAC-LC)32 to 192 Kbps (MP2L2)8 to 320 Kbps (MP3)
Audio Sampling Rate
8 kHz16 kHz32 kHz48 kHz
Environment Noise Filtering
Yes
Network
Protocols
TCPIP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSLTLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Simultaneous Live View
Up to 6 channels
API
ONVIF (Profile S, Profile T, Profile G),ISAPI,SDK,ISUP
UserHost
Up to 32 users
3 user levels administrator, operator, and user
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTPHTTPS, WSSE and digest authentication for Open Network Video Interface, RTPRTSP over HTTPS, control timeout settings, security audit log, TLS 1.11.21.3, host authentication (MAC address)
Network Storage
NAS (NFS, SMBCIFS),Auto Network Replenishment (ANR)
Client
iVMS-4200,Hik-Connect,Hik-Central
Web Browser
Plug-in free live view Chrome 80+, Firefox 80+, Edge 89+,
Local service Chrome 80+, Firefox 80+, Edge 89+
Image Parameters Switch
Yes
Image Settings
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
DayNight Switch
Day,Night,Auto,Schedule
Image Enhancement
BLC,HLC,3D DNR
SNR
≥ 52 dB
Wide Dynamic Range (WDR)
130 dB
Privacy Mask
8 programmable polygon privacy masks
Interface
Ethernet Interface
1 RJ45 10 M100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSDmicroSDHCmicroSDXC card, up to 512 GB
Built-in Speaker
Max. power consumption 2 W, max. sound pressure level 10 cm 120 dB.
Audio
Built-in Microphone Arrayed dual-microphone,1 input (line in), two-core terminal block, max. input amplitude 3.3 Vpp, input impedance 4.7 KΩ, interface type non-equilibrium,
1 output (line out), two-core terminal block, max. output amplitude 3.3 Vpp, output impedance 100 Ω, interface type non-equilibrium
Alarm
2 input, 2 output (max. 24 VDC24 VAC, 1 A)
Reset Key
Yes
Power Output
12 VDC, max. 100 mA
Event
Basic Event
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Smart Event
Scene change detection, audio exception detection, defocus detection
Linkage
Upload to FTPNASmemory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,strobe light
Deep Learning Function
Face Capture
Yes
Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle), people counting
General
Power
12 VDC ± 25%, 1.41 A, max. 17 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE IEEE 802.3at, Class 4, max. 18 W
Material
Front cover metal, body metal, bracket Metal
Dimension
286.7 mm × 93.3 mm × 91.2 mm (11.3 × 3.7 × 3.6)
Package Dimension
386 mm × 156 mm × 155 mm (15.2 × 6.1 × 6.1)
Weight
Approx. 1250 g (2.8 lb.)
With Package Weight
Approx. 1800 g (4.0 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
General Function
Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
Language
33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Flashing Light
White Light
Approval
EMC
CE-EMC EN 550322015+A12020, EN 50130-42011+A12014, EN IEC 61000-3-22019+A12021, EN 61000-3-32013+A12019+A22021,
RCM ASNZS CISPR 32 2015,
IC ICES-003 Issue 7,
KC KN32 2015, KN35 2015
Safety
UL UL 62368-1,
CB IEC 62368-1 2014+A11,
CE-LVD EN 62368-1 2014A11 2017
Environment
CE-RoHS 201165EU
Protection
IP67 IEC 60529-2013
Anti-Corrosion Protection
NEMA 4X (NEMA 250-2018)
