- Camera
- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & NightICR
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Slow ShutterMax. 16 times
- Lens
- Lens Type2.8 mm, 3.6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 126°
3.6 mm, horizontal FOV: 84°, vertical FOV: 46°, diagonal FOV: 98°
- Lens MountM12
- Microphone
- Pickup DistanceIn a radius of up to 5 m
- Amount1
- Speaker
- Rated Power2 W
- Speaker RangeIn a radius of up to 5 m
- Functions
- Audio FunctionEcho Cancellation, AI Noise Reduction, Automatic Gain Control
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light Range
IR: Up to 25 m,
White Light: Up to 20 m
- Image
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
- Image SettingsBrightness, Contrast, Sharpness, Anti-banding, AGC
- Frame RateTVI: 1080p @25 fps/30 fps
- Day/Night ModeAuto/Color
- Wide Dynamic Range (WDR)≥120 dB
- Image Enhancement
WDR,
BLC,
HLC,
Global,
HLS
- Noise Reduction3D DNR
- White Balance
Auto,
Manual
- Interface
- Video Output1 HD analog output
- Event
- Light AlarmFlashing Light Alarm (Red and Blue)
- Audible AlarmYes
- General
- Power
12 VDC ± 25%, max. 8.7 W
*You are recommended to use one power adapter to supply the power for one camera. If a high-impedance cable is used (such as the 18 m extension cable in the kit package), a 15 VDC adapter is required.
- MaterialPlastic
- Dimension179 mm × 69.08 mm × 65.98 mm (7.05″ × 2.72″ × 2.60″)
- WeightApprox. 280 g (0.62 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
- CommunicationHIKVISION-C
- LanguageEnglish
- Approval
- ProtectionIP67
