Image Sensor
[Bullet channel]
1/2.8 Progressive Scan CMOS
[PTZ channel]
1/2.8 Progressive Scan CMOS”
Min. Illumination
[Bullet channel]
Color: 0.005 Lux @ (F2.0, AGC ON), B/W: 0.005 Lux @ (F2.0, AGC ON), 0 Lux with IR
[PTZ channel]
Color: 0.005 Lux @ (F2.0, AGC ON), B/W: 0.005 Lux @ (F2.0, AGC ON), 0 lux with IR
Shutter Speed
1 s to 1/30,000 s
Slow Shutter
Yes
Day & Night
ICR
Max. Resolution
[Bullet channel] 2560 × 1440, [PTZ channel] 2560 × 1440
Lens
Focal Length
[Panoramic channel] 2.8 mm, [PTZ channel] 8 mm
FOV
[Panoramic channel]
horizontal field of view: 94°, vertical field of view: 49°, diagonal field of view: 114°,
[PTZ channel]
horizontal field of view: 44°, vertical field of view: 24°, diagonal field of view: 51°
Aperture
[Bullet channel] F1.6, [PTZ channel] F1.6
Illuminator
Supplement Light Type
[Bullet channel] Hybrid (IR and White Light), [PTZ channel] Hybrid (IR and White Light)
Supplement Light Range
[Bullet channel]: up to 30 m, [PTZ channel]: up to 30 m
Smart Supplement Light
Yes
PTZ
Movement Range (Pan)
[Panoramic channel] 0° to 355°, [PTZ channel] 0° to 345°
Movement Range (Tilt)
[Bullet channel] 7° to 17° (manually adjust), [PTZ channel] 0° to 80°
Pan Speed
Pan speed: configurable from 4° to 25°/s, preset speed: 25°/s
Tilt Speed
Tilt speed: configurable from 4° to 20°/s, preset speed 20°/s
Presets
300
Power-off Memory
Yes
Video
Scalable Video Coding (SVC)
Yes
Region of Interest (ROI)
1 fixed region for main stream
Main Stream
[Bullet channel]
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
[PTZ channel]
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream
[Bullet channel]
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
[PTZ channel]
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Video Compression
Main stream: H.265/H.264/Smart264/Smart265,
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate
32 Kbps to 4 Mbps
H.264 Type
Baseline profile,Main profile,High profile
H.265 Type
Main profile
Audio
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate
64 Kbps(G.711ulaw/G.711alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 to 160 Kbps(MP2L2)/16 to 64Kbps(AAC-LC)/8 to 160 Kbps(MP3)/8 to 48 Kbps(PCM)
Audio Sampling Rate
8 kHz/16 kHz
Environment Noise Filtering
Yes
Network
Protocols
TCP/IP, SMTP, RTSP, FTP, WebSockets, IGMP, WebSocket, Qos, RTCP, HTTPS, PPPoE, SNMP, NTP, RTP, UDP, DNS, HTTP, DHCP, Bonjour, 802.1x, IPv4, IPv6, DDNS, ICMP, UPnP
API
ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
Security
Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter
Simultaneous Live View
Up to 20 channels
User/Host
Up to 32 users. 3 user levels: administrator, operator, and user
Client
iVMS-4200,Hik-Connect,Hik Partner Pro
Web Browser
Chrome 31 to 44, Firefox 30 to 51, Safari 8.0+
Image Settings
Saturation, brightness, contrast, sharpness
Wide Dynamic Range (WDR)
Digital WDR
SNR
≥ 52 dB
Day/Night Switch
Day,night,auto,schedule
Image Enhancement
BLC,HLC,3D DNR
Privacy Mask
[Bullet channel] 4 programmable polygon privacy masks, [PTZ channel] 4 programmable polygon privacy masks
Image Parameters Switch
Yes
Interface
Ethernet Interface
1 RJ45 10 M/100M self-adaptive Ethernet port
On-board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Reset
Yes
Event
Basic Event
Motion detection (support alarm triggering by specified target types (human and vehicle)), exception
Linkage
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,audible warning
General
Material
PC
General Function
Mirror,password protection,watermark,IP address filter
Power
12 VDC ± 25%, 1.5 A, max. 18 W, Ø5.5 mm coaxial power plug, reverse polarity protection,
PoE: IEEE 802.3at, Class 4, max. 21.5 W
Operating Condition
-30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)
Dimension
134 mm × 213.5 mm × 291.7 mm (5.3″ × 8.4″ × 11.5″)
Weight
Weight: 1000 g (2.2 lb.)
With Package Weight: 1500 g (3.3 lb.)
Approval
Protection
IP66 Standard, Surge Protection and Voltage Transient Protection
