- External interface
- Network interface1, RJ45 10/100 M self-adaptive Ethernet interface
- Two-way audio input1, 3.5 mm interface (audio input multiplex)
- Serial interface
1, RS-485, half-duplex
1, RS-232
- Alarm in/out
Alarm in：1-ch
Alarm out：1-ch
- Storage
- Capacity4 TB for network single hard disk, 128 GB for micro SD card
- General
- Weight≤ 1 kg (2.2 lb)
- Power supply12 VDC, 2-pin connector
- Working temperature-10 to +55ºC
- Working humidity10 to 90 %
- Consumption≤ 6 W
- (W × D × H)114 × 47.5 × 127.5 mm (4.5″ ×1.9″ ×5.0″)
- Network management
- Network protocols1, RJ45 10/100 M self-adaptive Ethernet interface
- Video/Audio input
- Video input
1-ch, VGA
1-ch, HDMI
- HDTVI inputN/A
- AHD inputN/A
- HDCVI inputN/A
- CVBS inputN/A
- Audio input1-ch, 3.5 mm interface (two-way audio multiplex)
- Audio output
1-ch, 3.5 mm interface (linear, 600Ω)
Video
- Synchronous playbackN/A
- Video/Audio encoding
- Video compressionH.264/MJPEG
- Audio compressionG.711u/G.711a/AAC
- Main streamEncoding at HD resolution of 1080p/720p/UXGA, etc.
- Frame rate1/16 FPS to full frame rate (full frame rate includes 25/30/50/60 frames, depending on input signal)
- Video bit rate32 Kbps to 8192 Kbps, up to 16 Mbps
- Audio bit rate16Kbps/128Kbps
- Dual streamDual stream Sub stream resolution: W
