Video and Audio
IP Video Input 4-ch
Incoming Bandwidth 40 Mbps
Outgoing Bandwidth 60 Mbps
HDMI Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
LCD Output 11.6-inch LCD, 1366 × 768
Audio Output 1-ch, 3.5 mm connector
1-ch, built-in speaker
Two-Way Audio 1-ch, 3.5 mm connector
Decoding
Decoding Format H.265+/H.265/H.264+/H.264
Recording Resolution
6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous playback 4-ch
Decoding Capability 4-ch@4 MP (15 fps), 4-ch@1080p (30 fps)
Stream Type
Video, Video & Audio
Network
Remote Connection
16
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface
1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Wireless Parameter
Frequency Band 2.4 GHz
Antenna Structure 2 × 2MIMO
Transmission Speed 300 Mbps
Transmission Standard IEEE 802.11b/g/n
Auxiliary Interface
SATA 1
Capacity Up to 6 TB capacity
USB Interface 2 × USB 2.0
General
Power Supply 12 VDC, 1.5 A
Consumption ≤ 10 W (without HDD)
Working Temperature 0 °C to 40 °C (32 °F to 104 °F)
Working Humidity 10 to 90 %
Dimension (W × D × H) 300 x 230 x 46.3 mm (11.8″ × 9.0″ × 1.8″)
Weight ≤ 1 kg (without HDD, 2.2 lb.)
Certification
FCC
Part 15 Subpart B, ANSI C63.4-2014
CE
EN50130-4, EN 61000-3-2,EN 61000-3-3
