Motion Detection 2.0
Human/Vehicle Analysis
4-ch
Video and Audio
IP Video Input
16-ch
Incoming Bandwidth
160 Mbps
Outgoing Bandwidth
80 Mbps
HDMI Output
4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output
1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode
HDMI/VGA simultaneous output
Audio Input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1kΩ, using the audio input)
Decoding
Decoding Format
H.265/H.265+/H.264/H.264+
Recording Resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback
16-ch
Decoding Capability
1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)
Stream Type
Video, Video & Audio
Audio Compression
G.711ulaw, G.711alaw, G.722, G.726, AAC, MP2L2
Network
Remote Connection
32
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
≤ 150 W
Standard
IEEE 802.3 af/at
Wireless Parameter
SIM/UIM Card Slot
1 micro SIM card slot, on rear panel
SMA Antenna Interface
1 4G interface, antenna module cable length: 3 m
1 ANT interface for GPS antenna (GPS antenna is optional)
Wireless Standard
GSM/EDGE: 850/900/1800MHz
WCDMA: B1/B5/B8
LTE-FDD: B1/B3/B5/B7/B8/B20/B28
LTE-TDD: B38/B40/B41
Auxiliary Interface
SATA
2 SATA interfaces
Capacity
Up to 8 TB capacity for each HDD
USB Interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
General
Power Supply
100 to 240 VAC, 50 to 60 Hz
Consumption
≤ 15 W (without HDD and PoE off)
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10 to 90 %
Dimension (W × D × H)
385 × 315 × 52 mm (15.2″ × 12.4″ × 2.0″)
Weight
≤ 3 kg (without HDD, 6.6 lb.)
