DS-E08NI-Q1

Video and Audio
IP Video Input
8-ch
Incoming Bandwidth
60 Mbps
Outgoing Bandwidth
60 Mbps
HDMI Output
1920×1080/60Hz，1600×1200/60Hz，1280×1024/60Hz，1280×720/60Hz
Decoding
Decoding Format
H.265,Smart265,H.264,Smart264
Recording Resolution
4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback
4-ch
Decoding Capability
4-ch@1080p (25 fps)
Stream Type
Video, Video & Audio
Audio Compression
G.711ulaw/G.711alaw/G.722/G.726
Network
Remote Connection
128-ch
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface
1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Auxiliary Interface
Capacity
1TB SSD (pre-installed)
USB Interface
Rear panel: 2 × USB 2.0
General
Power Supply
12 VDC, 1A
Consumption
≤ 10 W (with SSD)
Working Temperature
-10 °C to 50 °C (14 °F to 122 °F)
Working Humidity
10 to 90 %
Dimension (W × D × H)
95 × 97 × 27 mm (3.7″ × 3.8″ × 1.1″)
Weight
≤ 0.24 kg
Certification
CE
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
