- System
- Operating system Linux
- Display
- Screen size7 inch
- Operation method Capacitive touch screen
- Type IPS
- Resolution600 × 1024
- Video
- Lens2
- Resolution2 MP
- Wide Dynamic Range (WDR)Support
- Video standard PAL (Default)/NTSC
- Network
- Wired network Support
- Wi-Fi Support, 2.4 G, 802.11b/g/n
- Bluetooth Support
- Interface
- Network interface1 RJ-45, 10/100/1000 M self-adaptive
- Lock control1
- Exit button1
- Door contact input1
- Alarm input2
- Alarm output1
- TAMPER1
- RS-4851 RS-485 (Half duplex, HIKVISION)
- Wiegand1 Wiegand(Hik 26bit,Hik 34bit)
- USB1 (For Module)
- Audio output interface1 (3.5 mm)
- Capacity
- Face capacity10,000
- Fingerprint capacity10,000 (With fingerprint module)
- Card capacity50,000
- Event capacity150,000
- Authentication
- Face recognition distance0.3 to 3 m
- Face recognition accuracy rate≥ 99%
- Face recognition duration＜ 0.2 s per person
- Card typeM1 card; Felica card; DES fire card
- General
- Power supply12 VDC to 24 VDC, 2 A
- Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity0 to 90% (no condensing)
- Protective levelIP65
- Dimensions110.5 mm × 209.2 mm × 24 mm (4.35″ × 8.24″ × 0.94″)
- Weight
Gross Weight：1.06 kg (2.34 lb)
Net Weight：0.57 kg (1.26 lb)
- Language English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Japanese, Korean, Traditional Chinese, French and Turkish
- Function
- Advertisement Support
- Face anti-spoofing Support
- Audio prompt Support
- Time synchronization Support
- Fingerprint recognition Support
