- Network
- Wired network10/100 Mbps self adaptive
- Interface
- Network interface1
- Lock control2
- Exit button2
- Door contact input2
- Alarm input4
- Alarm output4
- TAMPER1
- RS-4852 for card reader (1 for communication, 1 for redundancy; each interface can connect up to 4 readers)
- Wiegand4, standard 26/34 input, supports custom Wiegand settings
- Fire interfaceSupport
- Capacity
- Linked door capacity2
- Linked card reader capaciry4 RS-485 card readers (OSDP protocol) and 4 Wiegand card readers
- General
- BatteryCharge and discharge
- Power supply12 ± 15% VDC
- Power consumption≤ 72 W
- Working temperature-10 °C to 55 °C (14 °F to 131 ° F)
- Working humidity0% to 90% (No condensing)
- Installation Wall mounting
- Language English, Thai, Traditional Chinese, Indonesian, Vietnamese, Arabic, Spanish (Europe), Spanish (South America), Italian, French, Dutch, Russian, Ukrainian, Portuguese (Europe), Portuguese (Brazil), Serbian, Croatian, Bulgarian, German, Greek, Romanian and Turkish
- Function
- Configuration via Web browser Support
- Multi-factor authentication Support
- Anti-passback Support
- Multi-door interlocking Support
