- Device interfaces
- Alarm input2
- Network interface/
- Two-Wire interface2, 1 for input 1 for output
- Power interface48 V，powered by DS-KAD7060EY or DS-KAD7061EY
- General
- ButtonReset Button
- Power consumption≤ 4 W
- Indicator3（IN、OUT、ERROR）
- Working temperature-10 °C to 55 °C (14 °F to 127 °F)
- Working humidity10% to 90% (no-condensing)
- Dimension (W × H × D)52.5 mm × 104 mm × 42.1 mm (2.07″ × 4.09″ × 1.66″)
- InstallationRail mounting, screw mounting
