- System parameters
- Operation systemLinux
- ROM1 GB
- RAM4 GB
- ProcessorEmbeded high performance processor
- Display parameters
- Screen size4.3-inch
- Operation method/
- TypeColorful LCD
- Resolution800 × 480
- Video parameters
- Lens2 × 2 MP HD camera
- Resolution
Main stream: 1080p@30fps, 720p@30fps
Sub stream: VGA@25fps, VGA@30fps
- FOV/
- Wide dynamic range (WDR)Digital WDR/120 dB
- Supplement lightIR light, up to 3 m
- Video compression standardH.264
- Audio parameters
- Audio input1 built-in omnidirectional microphone
- Audio compression standardG.711 U、G.711 A、Opus、AAC-LD、AAC-LC、G.726、G.722.1
- Audio output1 built-in loudspeaker
- Audio compression bitrate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Capacity
- User capacity10,000
- Face capacity5000
- Card capacity50,000
- Fingerprint capacity5000
- Network parameters
- Network protocolTCP/IP, RTSP
- Wi-Fi/
- Bluetooth/
- 3G/4G/
- Device interfaces
- Alarm input4
- Network interface1 RJ-45 10/100/1000 Mbps self-adaptive
- TAMPER1
- Exit button1
- RS-4852 RS-485 (Half duplex, HIKVISION)
- USB/
- Wiegand/
- TF card/
- Alarm output/
- Lock control2 relays, Max. 30 VDC, 2 A
- Door contact input1
- General
- ButtonPhysical buttons
- InstallationFlush mounting
- Indicator/
- WeightNet weight: 1.23 kg Gross weight: 1.515 kg
- Protective levelIP65
- Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity10% to 90% (no-condensing)
- Dimension (W × H × D)373 mm × 124 mm × 43.7 mm (14.69″ × 4.88″ × 1.72″)
- Power supply12 VDC, 1.5 A
- Application environmentOutdoor
- Power consumption≤ 13 W
- LanguageEnglish, TraChinese, Brazilian Portuguese, Spanish, Russian, Turkish, Arabic, Vietnamese, Kazak, Uzbek, Ukrainian, Estonia, Lithuanian, Latvian, Czech
