Cameras 256
Video Intercom Devices 64
Alarm Inputs 64
Alarm Outputs 64
ANPR Cameras 32
Facial Recognition Cameras 16
Security Radars and Radar PTZ Cameras 16
Recording Server 16
People Counting Cameras 16
Heat Map Cameras 16
Thermal Cameras 16
Queue Management Cameras 16
Recording Schedule
Recording Schedule 64
Recording Schedule Template 32
Event & Alarm
Event and Alarm Rules 1,500
Storage of Events or Alarms without Pictures 100/s
Events or Alarms Sent to Clients 15/s
32 Clients/s
Storage
Picture Storage
20/s
*Including event/alarm pictures, face pictures, and vehicle pictures.
Data Retention Period
Stored for 3 Years
Users and Roles
Concurrent Accesses via Web Clients, Control Clients, and OpenAPI Clients
32
Concurrent Accesses via Mobile Clients and OpenAPI Clients
32
Users
256
Roles
32
Entrance & Exit
Vehicle Lists
100
Vehicles per Vehicle List
5,000
Lanes
8
Vehicle Passing Frequency in Each Lane
1 Vehicle/s
Face Comparison
Persons with Profiles for Face Comparison
10,000
Face Comparison Groups
16
Persons in One Face Comparison Group
1,000
Access Control
Persons with Credentials for Access Control
10,000
Total Credentials (Card + Fingerprint)
50,000
Cards
50,000
Fingerprints
40,000
Profile Pictures
10,000
Access Points (Doors + Outdoor Station)
128
Access Levels
256
Time and Attendance
Persons for Time and Attendance
10,000
Shift Schedules
128
Major Leave Types
64
Minor Leave Types of One Major Type
128
Smart Wall
Decoding Devices
32
Smart Walls
32
Views Auto-Switched Simultaneously
32
System
Main Processor
Quad-Core Intel® Xeon® Processor E3 V5 Series
Memory
16GB DDR4. ECC parity. Extendable up to 64 GB
System Bandwidth
Multi-address/net fault-tolerance mode: 768 Mbps;
Load balancing mode: 1,000 Mbps
Number of Storage Channels
256
Video and Audio
HDMI 1 Output
1024 × 768/60 Hz
HDMI 2 Output
1024 × 768/60 Hz
VGA Output
1024 × 768/60 Hz
Video Output Mode
HDMI1/HDMI2/VGA simultaneous output
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Audio Input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Network
Network Interface
4 × RJ45 10M/100M/1000M self-adaptive Ethernet interface
RAID
RAID Type
RAID0, RAID1, RAID5, RAID6, RAID10, RAID50, RAID60, JBOD
Auxiliary Interface
SATA
16 SATA interfaces supporting hot-swapping (except the HDD at the first slot which contains the system disk)
eSATA
1 eSATA interface
Capacity
Up to 10 TB capacity for each disk
USB Interface
Front panel: 2 × USB 2.0;
Rear panel: 2 × USB 3.0
Alarm In/Out
16/8
Extension Board
The extension board is optional to support. It has four 10M/100M/1000M optical interfaces (1.25 Gbps SFP module), eight RS-485 interfaces, 32 alarm inputs, and 16 alarm outputs.
General
Consumption
≤ 140 W (without HDD)
Working Temperature
0 °C to 50 °C (32 °F to 122 °F);
Working Humidity
10% to 90% RH (no freezing and no condensation)
Chassis
3U
Dimension (W × D × H)
446 × 495 × 133 mm (17.6 × 19.5 × 5.2 inch)
Weight
≤ 17 kg (37.5 lb.)
